Lexus Toyota IS300 JZX90 JZX100 JZX110 Angle Kit - Style Drift Rats - Perfect for Drifting and Performance Tuning

Product Description

Elevate your driving experience with our meticulously crafted angle kits, specifically engineered to enhance steering performance for IS300, JZX, and JZS chassis. Designed with an impressive steering angle of up to 50°, these kits are a formidable upgrade from stock configurations.

Premium Construction:

• Aerospace Grade 7075-T6 Aluminum: Each kit is machined in-house from high-quality aluminum, ensuring durability and precision performance.
• Chromoly Steel Dowels: The locating dowels are crafted from robust chromoly steel, pre-pressed into the knuckle adapter for added strength.

Compatibility and Ball Joint Options:

• Versatile Compatibility: Compatible with any IS300, JZX100, JXZ110 or JZS ball joint, including preferred options like Moog.
• Exclusion Note: Not compatible with UCF (LS400/Celsior) or JZS160/161 (Aristo/GS300) chassis.

Roll Center Correction:

• 35mm of Correction: Achieve 35mm of roll center correction, restoring ideal suspension geometry to minimize understeer and body roll.

Ackerman Adjustment:

• Stock-Like Ackerman: Maintains close-to-stock Ackerman angles, ensuring consistent front grip throughout the entire steering range.

Installation Details:

• Ball Joint Modification: Requires modification of the lower ball joint by cutting off the old tie rod end mounting point.
• Front Ride Height Adjustment: Installing the adapter will lower the front ride height by 35mm.
• Tie Rod Compatibility: Requires either extended inner tie rods (cut to fit) or an extended length outer tie end based on chassis and lower control arm length.

Max Angle and Wheel Clearance Tips:

• Alternate Tie Rod Lengths: Achieve maximum angle by using alternate inner and outer tie rod lengths compatible with your chassis.
• Wheel Clearance Suggestions: To maximize wheel clearance and prevent rubbing, consider using IS300 or JZX110 forward lower control arms (caster arms).

Vehicle Fitment:

• Lexus IS300 2001-2005
• Compatible with any IS300, JZX100, JXZ110 or JZS ball joint

For inquiries about the ideal combinations for your setup, utilize our shop chat for quick responses. Elevate your steering capabilities and experience unparalleled control with our precision-engineered angle kits.
